Hitachi HTA-DD3E - ICs and Diodes Parts List

 57 
HTA-DD3
PRODUCT SAFETY NOTE: Components marked with a have special characteristics important to safety. Before replacing any of these
components, please read carefully the Service Manual.
DESCRIPTION
SYMBOL
NO.
PART NO.
DESCRIPTIONPART NO.
SYMBOL
NO.
TR711 CA00292R TRS . DTA144EKT146
TR712 2316691R TRS DTC144EKAT
TR801 2328625T TRS 2SB647C TZ
TR802 CF01191R TRS 2SA988-T (E/F)
TR804 2325691R TRS. CHIP 2SC2412KT146R
TR805 CA00691R TRS 2SA1037AKT146R
TR806 2325691R TRS. CHIP 2SC2412KT146R
TR807 2325691R TRS. CHIP 2SC2412KT146R
TR808 2325691R TRS. CHIP 2SC2412KT146R
TR809 2325691R TRS. CHIP 2SC2412KT146R
TR810 CA00691R TRS 2SA1037AKT146R
TR811 2325691R TRS. CHIP 2SC2412KT146R
TR812 CA00301R TRS DTC143EKAT146
TR813 2325691R TRS. CHIP 2SC2412KT146R
TR814 CA00291R TRS DTA114EKT146
TR815 2325691R TRS. CHIP 2SC2412KT146R
TR816 2325691R TRS. CHIP 2SC2412KT146R
TR817 2325691R TRS. CHIP 2SC2412KT146R
TR818 2325691R TRS. CHIP 2SC2412KT146R
TR819 2325691R TRS. CHIP 2SC2412KT146R
TR820 2325691R TRS. CHIP 2SC2412KT146R
TR821 CF01191R TRS 2SA988-T (E/F)
TR901 2318303T TRS 2SC1740S (S) TP
IC1 2300412W IC LA1265S
IC2 CP03061 IC LA3401
IC3 CK09831R IC LC72131MD-TRM
IC4 CP02414 IC KIA7809PI
IC91 CK04451 IC SAA6579T/V1 (D-C850) [E, EBS]
IC92 CK04471R IC LC7074M [E, EBS]
IC101 CK02301T IC NJM2068M
IC102 CK32031 IC TC9273F-007
IC151 2388301R IC BA4558F-T1
IC152 2388301R IC BA4558F-T1
IC171 CK01451R IC BA15218F-E2
IC172 CK01451R IC BA15218F-E2
IC173 CK01451R IC BA15218F-E2
IC201 CK09541R IC HD74HCT245TELL
IC202 CK32042 IC AK4527
IC203 CK33841U IC ZR38650
IC204 CK34871A IC MX27C400MC-12
IC205 CK01451R IC BA15218F-E2
IC206 CK01451R IC BA15218F-E2
IC207 CK01451R IC BA15218F-E2
IC208 CK01451R IC BA15218F-E2
IC209 CK01451R IC BA15218F-E2
IC210 CK33861U IC IS61C3216-15T
IC211 CK33861U IC IS61C3216-15T
IC212 CK34041R IC TC7SET04F
IC213 CZ00671R IC BA033FP-E2
IC214 CZ00672R IC BA05FP-E2
IC301 CP06421 IC LC7536
ICS:
IC302 CP06421 IC LC7536
IC303 CP06421 IC LC7536
IC304 CK02301T IC NJM2068M
IC305 CK02301T IC NJM2068M
IC306 CK02301T IC NJM2068M
IC307 CK02301T IC NJM2068M
IC308 CK02301T IC NJM2068M
IC309 CK02301T IC NJM2068M
IC401 CP07391 IC STK413-010B
IC501 CP07401 IC STK412-010B
IC601 CK32011R IC TC74HC151AF (EL)
IC602 DT00261 TORX178B (OPTICAL OUT)
IC603 DT00261 TORX178B (OPTICAL OUT)
IC604 DT00261 TORX178B (OPTICAL OUT)
IC605 CP07201 IC BA7625
IC606 CP07211 IC BA7612N
IC607 CP07211 IC BA7612N
IC608 CP07211 IC BA7612N
IC609 CK34321R IC BA7626F
IC610 CP07201 IC BA7625
IC611 CK01811R IC BU4066BCF-T1
IC701 CK32051 IC LC75721E
IC702 CW00202 I/R RECEIVER MODULE PIC-28043
IC751 CK01451R IC BA15218F-E2
IC801 CK34282 IC TMP87PS71F
IC802 CP04231 IC BA05T
IC803 CP02412 IC KIA7806API
IC804 CP02416 IC KIA7812API
IC805 CP05542 IC KIA7912PI
IC806 CP04231 IC BA05T
IC951 CK32021R IC TC9164AF (ELP)
D1 2398921T DIODE ISS133T-72
D2 2398921T DIODE ISS133T-72
D3 2398921T DIODE ISS133T-72
D4 2398921T DIODE ISS133T-72
D101 2398921T DIODE ISS133T-72
D102 2398921T DIODE ISS133T-72
D103 2398921T DIODE ISS133T-72
D201 CC00003R DIODE ISS355TE-17
D202 CC00003R DIODE ISS355TE-17
D203 CC00003R DIODE ISS355TE-17
D401 2398921T DIODE ISS133T-72
D402 2398921T DIODE ISS133T-72
D403 2398921T DIODE ISS133T-72
D404 2398921T DIODE ISS133T-72
D405 2398921T DIODE ISS133T-72
D406 2398921T DIODE ISS133T-72
D407 2398921T DIODE ISS133T-72
D408 2398921T DIODE ISS133T-72
D409 2398921T DIODE ISS133T-72
D410 2398921T DIODE ISS133T-72
DIODES:
