Hitachi HTA-DD3E - Fuses, Coils, Switches Parts List

 58 
HTA-DD3
PT001 BT01782 POWER TRANSFORMER [E, EBS]
PT001 BT01783 POWER TRANSFORMER [W, WUN, WAU]
PT902 BT01413 SUB TRANSFORMER [E/BS]
PT902 BT01414 SUB TRANSFORMER [W, WUN, WAU]
F902 FN00225 FUSE T3.15A 250V [E, EBS]
F902 FN00341 FUSE T6.3A 250V [W, WUN, WAU]
F903 FN00225 FUSE T3.15A 250V [W, WUN, WAU]
F904 FN00223 FUSE T5A [E, EBS, W, WUN, WAU]
F905 FN00223 FUSE T5A [E, EBS, W, WUN, WAU]
F906 FN00224 GLASS FUSE 5X20MM T1A/250V
[E, EBS, W, WUN, WAU]
F907 FN00224 GLASS FUSE 5X20MM T1A/250V
L401 2227362 TRAP COIL 1.1UH
L402 2227362 TRAP COIL 1.1UH
L403 2227362 TRAP COIL 1.1UH
L501 2227362 TRAP COIL 1.1UH
L502 2227362 TRAP COIL 1.1UH
L801 2122239M AXIAL COIL LAL04 TB 100K
T3 BJ00251 AM IF COIL 950582285B
T4 BS00071 FM DISCRI.COIL
S1 2622521 SLIDE SWITCH [W, WUN, WAU]
S501 FE00181 SPK SWITCH SPW24-11
S702 FE00411R TACT SWITCH (SKQNABD010)
S703 FE00411R TACT SWITCH (SKQNABD010)
S704 FE00411R TACT SWITCH (SKQNABD010)
S705 FE00411R TACT SWITCH (SKQNABD010)
S706 FE00411R TACT SWITCH (SKQNABD010)
S707 FE00411R TACT SWITCH (SKQNABD010)
S708 FE00411R TACT SWITCH (SKQNABD010)
S709 FE00411R TACT SWITCH (SKQNABD010)
S710 FE00411R TACT SWITCH (SKQNABD010)
S711 FE00411R TACT SWITCH (SKQNABD010)
S712 FE00411R TACT SWITCH (SKQNABD010)
S713 FE00411R TACT SWITCH (SKQNABD010)
S714 FE00411R TACT SWITCH (SKQNABD010)
S715 FE00411R TACT SWITCH (SKQNABD010)
S716 FE00411R TACT SWITCH (SKQNABD010)
S717 FE00411R TACT SWITCH (SKQNABD010)
S718 FE00411R TACT SWITCH (SKQNABD010)
S719 FE00411R TACT SWITCH (SKQNABD010)
S720 FE00411R TACT SWITCH (SKQNABD010)
S721 FE00411R TACT SWITCH (SKQNABD010)
S722 FE00411R TACT SWITCH (SKQNABD010)
S723 FE00411R TACT SWITCH (SKQNABD010)
S724 FH00191 ENCODER
PRODUCT SAFETY NOTE: Components marked with a
have special characteristics important to safety. Before replacing any of these
components, please read carefully the Service Manual.
DESCRIPTION
SYMBOL
NO.
PART NO.
DESCRIPTIONPART NO.
SYMBOL
NO.
D501 2398921T DIODE ISS133T-72
D502 2398921T DIODE ISS133T-72
D503 2398921T DIODE ISS133T-72
D504 2398921T DIODE ISS133T-72
D505 2398921T DIODE ISS133T-72
D506 2398921T DIODE ISS133T-72
D507 2398921T DIODE ISS133T-72
D508 2398921T DIODE ISS133T-72
D509 2398921T DIODE ISS133T-72
D601 2398921T DIODE ISS133T-72
D602 2398921T DIODE ISS133T-72
D701 2398921T DIODE ISS133T-72
D702 2398921T DIODE ISS133T-72
D703 2398921T DIODE ISS133T-72
D704 2398921T DIODE ISS133T-72
D804 2337461W S4VB20 (FORMED)
D805 2337461W S4VB20 (FORMED)
D806 2337461W S4VB20 (FORMED)
D808 2337461W S4VB20 (FORMED)
D809 2398921T DIODE ISS133T-72
D810 2398921T DIODE ISS133T-72
D811 2398061T RECTIFIER DIODE IN4002 TAPE
D812 2398921T DIODE ISS133T-72
D813 2398061T RECTIFIER DIODE IN4002 TAPE
D814 2398061T RECTIFIER DIODE IN4002 TAPE
D815 2398921T DIODE ISS133T-72
D901 CH02053M RECTIFIER DIODE IN4002 TAPE
D902 CH02053M RECTIFIER DIODE IN4002 TAPE
D903 CH02053M RECTIFIER DIODE IN4002 TAPE
D904 CH02053M RECTIFIER DIODE IN4002 TAPE
D905 CH02053M RECTIFIER DIODE IN4002 TAPE
D906 CH02053M RECTIFIER DIODE IN4002 TAPE
D907 2398921T DIODE ISS133T-72
ZD401 2348213Q ZENER DIODE MTZJ15C
ZD402 2348213Q ZENER DIODE MTZJ15C
ZD403 2339032Q ZENER DIODE HZS6C2LTD
ZD404 2339032Q ZENER DIODE HZS6C2LTD
ZD405 2339032M ZENER DIODE HZS6C2L
ZD501 2348213Q ZENER DIODE MTZJ15C
ZD502 2348213Q ZENER DIODE MTZJ15C
ZD503 2339032M ZENER DIODE HZS6C2L
ZD504 2339032M ZENER DIODE HZS6C2L
ZD505 2339032M ZENER DIODE HZS6C2L
ZD506 2339032M ZENER DIODE HZS6C2L
ZD703 2348161M DIODE MTZJ9.1A
ZD704 2348111M DIODE MTZJ5.6A
ZD801 2339232Q DIODE HZS30-2L
ZD802 2348051Q DIODE MTZJT-773.3A
ZD804 2348051Q DIODE MTZJT-773.3A
LED701 CH01501 LED SLR-56VC3F
LED702 CH01501 LED SLR-56VC3F
LED703 CH01501 LED SLR-56VC3F
LED704 CH01501 LED SLR-56VC3F
SWITCHES:
COILS:
TRANSFORMERS:
FUSES:
