 59 
HTA-DD3
PRODUCT SAFETY NOTE: Components marked with a have special characteristics important to safety. Before replacing any of these
components, please read carefully the Service Manual.
DESCRIPTION
SYMBOL
NO.
PART NO.
DESCRIPTIONPART NO.
SYMBOL
NO.
S725 FE00411R TACT SWITCH (SKQNABD010)
S726 FE00411R TACT SWITCH (SKQNABD010)
S901 FE00361 POWER SWITCH SY16-22-1 (U99SI) T
S902 FG00011
VOLTAGE SELECTOR SWITCH [W, WUN ,WAU]
S903 FG00011 VOLTAGE SELECTOR SWITCH [W, WUN, WAU]
AP1 EV00586 CEE POWER CORD W/BUSH L=2M
[E,EBS,W,WUN]
AP1 EV00589 POWER CORD [WAU]
BL1 BH00531 MW ANT. COIL (BLOCK)
CF1 2134992
CER FILTER SFE 10.7MA8-A [W, WUN, WAU]
CF1 BN00101 CER. FILTER SFT 10.7MS2-A [E, EBS]
CF2 BN00101 CER. FILTER SFT 10.7MS2-A [E, EBS]
CF2 BN00111
CER FILTER SFE1 0.7MS2G-A [W, WUN, WAU]
CF3 BP00501 CER. FILTER BFU450C4N
CF4 BP00491 CERAMIC FILTER CMU2-456A16
CN3 ED01425 TXL 3P CONN
CN12 EF06919 KR-DA CONN 4P L=500MM
CN13 EF06892 KR-DA CONN 7P L=300MM
CN14 2909049 PH-SAN CONN 2P L=220MM
CN15 EF06879 KR-DA CONN 3P L=250MM
CN22 2909046L PH-SAN CONN 2P L=160MM
CN201 EF06809 3P KR-DA CONN L=240
CN202 EY00102 13P SOCKET 9110S-13
CN203 EY00097 9P SOCKET IMSA 9110S-09L
CN204 EF06824 4P KR-DA CONN L=140
CN205 EF06015 5P MX SHIELD CONNECTOR
CN206 EF06014 3P MX SHIELD CONNECTOR
CN1A ED00772 MX CONN 7P (52045-0745)
CN2A ED03326 19P FFC CON BASE
CN4A EY00073 B-B PIN HEADER IMSA-9110B-05
CN5A EY00079 B-B PIN HEADER IMSA-9110B-11L
CN6A EY00085 B/B PIN HEADER IMSA9110B-16
CN7A EY00071 B-B PIN HEADER IMSA-9110B-03
CN8A EY00074 6P PIN HEADER 9110B-06
CN9A EY00077 B-B PIN HEADER IMSA9110B-09
CN10A EY00077 B-B PIN HEADER 1MSA9110B-09
CN11A EY00074 6P PIN HEADER 9110B-06
CN16A EY00075 B-B PIN HEADER 1MSA9110B-07
CN17A EY00072 4P PIN HEADER 9110B-04
CN18A EY00072 4P PIN HEADER 9110B-04
CN19A EY00514 6P PIN HEADER 1MSA9130B-06
CN20A EY00518 10P PIN HEADER 1MSA9130B-10
CN21A EY00074 6P PIN HEADER 9110B-06
CN201A 2959052 3P PIN POST (A2001WV2-3P)
CN202A EY00082 B-B PIN HEADER 1MSA9110B-13
CN203A EY00077 B-B PIN HEADER 1MSA9110B-09
CN204A 2959053 4P PIN POST (A2001WV2-4P)
CN1B ED00321 MX BOTTOM/E CONN (52492-0720)
CN2B ED00323 19P FFC CON BOTTOM
CN4B EY00093 B-B SOCKET IMSA-9110S-05L
CN5B EY00099 B-B SOCKET IMSA-9110S-11L
CN6B EY00105 B/B SOCKET IMSA9110S-16L
CN7B EY00091 B-B SOCKET IMSA-9110S-03L
CN8B EY00094 6P SOCKET 9110S-06L
CN9B EY00097 B-B SOCKET 1MSA9110S-09L
CN10B EY00097 B-B SOCKET 1MSA9110S-09L
CN11B EY00094 6P SOCKET 9110S-06L
CN16B EY00095 B-B SOCKET 1MSA9110S-07L
CN17B EY00092 4P SOCKET 9110S-04
CN18B EY00092 4P SOCKET 9110S-04
CN19B EY00484 6P SOCKET 1MSA913S0S-06L
CN20B EY00488 B/B SOCKET 1MSA9130S-10L
CN21B EY00094 6P SOCKET 9110S-06L
E003 2729252R FUSE HOLDER (TAPING)
E004 2729252R FUSE HOLDER (TAPING)
E005 2729252R FUSE HOLDER [W, WUN, WAU]
E006 2729252R FUSE HOLDER [W, WUN, WAU]
E007 2729252R FUSE HOLDER (TAPING)
E008 2729252R FUSE HOLDER (TAPING)
E009 2729252R FUSE HOLDER (TAPING)
E010 2729252R FUSE HOLDER (TAPING)
E011 2729252R FUSE HOLDER (TAPING)
E012 2729252R FUSE HOLDER (TAPING)
E013 2729252R FUSE HOLDER (TAPING)
E014 2729252R FUSE HOLDER (TAPING)
ECP01 EP00062 EURO CONVERTER PLUG [EBS]
FB201 BM00288R BLM11B471SBPT
FB202 BM00288R BLM11B471SBPT
FB203 BM00288R BLM11B471SBPT
FB204 BM00288R BLM11B471SBPT
FB205 BM00288R BLM11B471SBPT
FB206 BM00288R BLM11B471SBPT
FB207 BM00288R BLM11B471SBPT
FB208 BM00288R BLM11B471SBPT
FB209 BM00288R BLM11B471SBPT
FB210 BM00288R BLM11B471SBPT
FB211 BM00288R BLM11B471SBPT
FB212 BZ01421 BL02RN1-R62
FB213 BZ01421 BL02RN1-R62
FB214 BZ01421 BL02RN1-R62
FB218 0195250R JAMPER CHIP
FB219 BM00288R BLM11B471SBPT
FB220 BM00288R BLM11B471SBPT
FB221 BM00288R BLM11B471SBPT
FB222 BM00288R BLM11B471SBPT
FB223 BM00288R BLM11B471SBPT
FB224 BM00288R BLM11B471SBPT
FB231 BZ01421 BL02RN1-R62
FB401 BZ01422M 8L01RN1-A62
FB402 BZ01422M 8L01RN1-A62
FB403 BZ01422M 8L01RN1-A62
FB404 BZ01422M 8L01RN1-A62
FB405 BZ01423R BL02RN2-R62
FB406 BZ01423R BL02RN2-R62
MISCELLANEOUS:
