19
A003/
A203
Base frequency setting 50.0 / 60.0
A004/
A204
Maximum frequency setting 50.0 / 60.0
A005 [AT] selection
• 00 Select between [O] and [OI] at [AT]
• 01 [O]+[OI] ([AT] input is ignored)
• 02 Select between [O] and keypad pot
• 03 Select between [OI] and keypad pot
00
A011 Pot./O–L input active range start frequency 0.0
A012 Pot./O–L input active range end frequency 0.0
A013 Pot./O–L input active range start voltage 0.
A014 Pot./O–L input active range end voltage 100.
A015 Pot./O–L input start frequency enable
• 00 Use A011 starting value)
• 01 Use 0 Hz
01
A016 External frequency filter time constant 2. / 8.
A020/
A220
Multi-speed frequency setting 0
A021
A022
A023
A024
A025
A026
A027..
..A035
Multi-speed frequency settings (for both motors) 0.0 / 0.0
0.0 / 0.0
0.0 / 0.0
0.0 / 0.0
0.0 / 0.0
0.0 / 0.0
......
0.0 / 0.0
A038 Jog frequency setting 1.00
A039 Jog stop mode
• 00 Free-run stop, jogging disabled during
motor run
• 01 Controlled deceleration, jogging disabled
during motor run
• 02 DC braking to stop, jogging disabled
during motor run
00
A041/
A241
Torque boost select
• 00 Manual torque boost
• 01 Automatic torque boost
00
A042/
A242
Manual torque boost value 5.0(A042)/
0.0 (A242)
A043/
A243
Manual torque boost frequency adjustment 3.0/(A043)
0.0(A243)
Func.
Code
Name / Description
Default
Val ue
–FE(F)/–FU
Set
Val ue
