Hitachi L2002 Series - C Group: Intelligent Terminal Functions

24
“C” Group: Intelligent Terminal Functions
B091 Stop mode selection
• 00 DEC (decelerate and stop)
• 01 FRS (free-run to stop)
00
B130 Over-voltage LADSTOP enable
• 00 Disable • 01 Enable
00
B131 Over-voltage LADSTOP level 380 / 760
B150 Carrier mode
• 00 Disable • 01 Enable
00
B151 Quick-start enable
• 00 Disable • 01 Enable
00
Func.
Code
Name / Description
Default
Value
–FE(F)/–FU
Set
Value
C001/
C201
Terminal [1] function Twenty-four option
codes available
(see page 28)
00
C002/
C202
Terminal [2] function 01
C003/
C203
Terminal [3] function 02 / 16
C004/
C204
Terminal [4] function 03 / 13
C005/
C205
Terminal [5] function 18 / 09
C011 Terminal [1] active state • 00 Normally open
[NO]
• 01 Normally
closed [NC]
00
C012 Terminal [2] active state 00
C013 Terminal [3] active state 00
C014 Terminal [4] active state 00 / 01
C015 Terminal [5] active state 00
C021 Terminal [11] function Ten option codes
available
(see page 29)
01
C022 Terminal [12] function 00
C026 Alarm relay terminal
function
05
C028 [AM] signal selection Two option codes
available
(see page 30)
00
Func.
Code
Name / Description
Default
Value
–FE(F)/–FU
Set
Value
