Intelligent Input Terminal Listing
Symbol Code Input Terminal Name
FW 00 Forward Run/Stop
RV 01 Reverse Run/Stop
CF1 02 Multi-speed select, Bit 0 (LSB)
CF2 03 Multi-speed select, Bit 1
CF3 04 Multi-speed select, Bit 2
CF4 05 Multi-speed select, Bit 3 (LSB)
JG 06 Jogging
DB 07 External DC braking
SET 08 Set (select) second motor data
2CH 09 2-stage accel and decel
FRS 11 Free-run stop
EXT 12 External trip
USP 13 Unattended start protection
SFT 15 Software lock
AT 16 Analog input voltage/current sel.
RS 18 Reset inverter
PTC 19 PTC thermistor thermal protection
STA 20 Start (3-wire interface)
STP 21 Stop (3-wire interface)
F/R 22 FWD, REV (3-wire interface)
PID 23 PID disable
PIDC 24 PID Reset
UP 27 Remote control Up func.
DWN 28 Remote control Down func.
UDC 29 Remote control data clearing
OPE 31 Operator control
ADD 50 Add frequency enable
F-TM 51 Force Terminal Mode
RDY 52 Quick Start Enable
S-ST 53 Special-Set (select) 2nd motor data
— 255 Not selected
