Hitachi P42A01 Service Manual

GENERAL SPECIFICATIONS
G-1 TV PDP PDP Size / Visual Size 42.32 inch / 1074.9 mmV
System Number of Pixels(H x V) 1024(H) x 1,080(V)
Color System PAL/SECAM
Speaker 4 Speaker
Position Front
Main Size 2.2 x 5.0 inch
Impedance 4 ohm
Tweeter Size 2.0 inch
Impedance 8 ohm
Sound Output MAX 10W + 10W
10%(Typical) ---
AV Input Receivable NTSC4.43 Yes
NTSC3.58 Yes
PAL60 Yes
G-2 Tuning
Broadcasting System Analog
U.K., I.R., CCIR,
FRENCH System
B/G, D/K, I/I, L
System
Digital
--
Tuner and System 1Tuner (Analog)
Receive CH Destination UK, I.R., CCIR Hyper+France CATV
CH Covera
g
Analog
IreE2~E4, X~Z+2,
S1~S10, E5~E12,
S11~S41,
Digital
--
Intermediat
e
Analog
BG/ II/ DK, L/ L'
(SECAM VL)
Frequency Picture(FP) 38.9/38.9/38.9/33.9MHz
Sound(FS) 33.4/32.9/32.4/40.4MHz
FP-FS 5.5/6.0/6.5/6.5MHz
Digital
--
Auto Tuning Method ALL Band (Not C.C.I.R. CH Plan)
Preset CH
Analog
99
Digital
--
Stereo/Dual TV Sound NICAM/A2 Dual
Tuner Sound Muting Yes
G-3 Power Power Source AC 220-240V AC 50/60Hz
DC ---
Power Consumption at AC 320 W at AC 230 V 50 Hz
at DC --
Stand by (at AC) 1 W at 230V 50Hz
Stand by (EPG Timer) --
Per Year -- kWh/Year
Protector Power Fuse Yes
Safety Circuit Yes
IC Protector(Micro Fuse) No
G-4 Regulation Safety (ORION) CE(EN60065:2002/BEAB)
Radiation (ORION) CE
X-Radiation ---
G-5 Temperature Operation
±0
o
C ~ +40
o
C
Storage
-20
o
C ~ +60
o
C
G-6 Operating Humidity Less than 80% RH
G-7 OSD Language English, Spanish, German, French,
Italian, Swedish, Dutch, Russian,
Portuguese, Turkish, Greek, Finnish,
Polish, Norwegian, Danish
G-8 Clock and
Clock --
Timer Clock Display --
Calendar
No
Sleep Timer Max Time 120 Min
Step 30 Min
On Timer Program(On Timer)
No
Off Timer Program(Off Timer)
No
Timer Back-up
No
A3-1

Hitachi P42A01 Specifications

General

Brand	Hitachi
Model	P42A01
Category	Plasma TV
Language	English
