4 Individual remote controls
PC-ARH
TCGB0106 rev.0 - 12/2014
163
4
3 Remove the decorative cover and place the remote control in the hole
for installation.
Nut
(eld supply)
4 Secure the remote to the bracket using the screws and connect the
cable as shown in the diagram.
Pass the cable
through the hopple
Insert the connector
5 Secure the remote to the xing bracket. First connect the top, and
then the bottom.
