3 Do not detach or reattach the connectors while energied
2 Detaching and reattaching the board connector
Do not under any circumstances detach or reattach the connectors while energied. That would destroy the board
components and fan motor. or both the indoor and outdoor boards, ensure that the smoothing capacitor has discharged its
electricity fully before you do your work.
The product comes equipped with many board connectors provided with lock mechanism. orcibly pulling any such part
without unlocking it will destroy it. Be on guard. When reconnecting it, insert it securely all the way home.
All the receptacles for connecting tab terminals are with a locking mechanism. orcibly pulling any such receptacle without
unlocking it will destroy it. Be on guard.
When reconnecting it, insert it securely all the way home.
Pinch the locking mechanism with your
fingers and pull it out unlocked.
Other instructions
1 Detaching and reattaching the receptacles for tab terminal
·Receptacle types and how to unlock them
ertical with a resin case
Hold the resin case and pull it out.
Mild resin cover
Horiontal with a mild resin cover
Hold the cancel button down on the
mild resin cover while pulling it out.
Cancel button
Locking
mechanism
