Hitachi RAK-18REF Service Manual

Remote Controller Manual
Remote Controller manual
Page 1~12
To obtain the best performance and ensure years of trouble free use, please read this instruction manual completely.
MODEL
RAR-7PE1
- 1 -
<0016692Y>
NAMES AND FUNCTIONS OF REMOTE CONTROLLER
This controls the operation function and timer setting of the room air conditioner. The range of control
is about 7 meters. lf indoor lighting is controlled electronically, the range of control may be shorter.
Precautions for Use
• Do not put the remote controller under direct sunlight and high temperature.
• Do not drop it on the fl oor, and protect it from water.
• If you press the FUNCTION button during operation, the air conditioner may stop for about 3 minutes
for protection before you can start it again.
Signal Transmission
MODE selector Button
Use this button to select the
operating mode. Every time
you press this button, the
mode will change from
(AUTO) (HEAT)
(DEHUMIDIFY)
(COOL) and (FAN)
cyclically.
(
Page 3)
ECO Button
Use this button to set the
ECO mode.
(
Page

)
TIMER OFF Button
Select the turn OFF time.
(
Page

)
TIMER ON Button
Select the turn ON time.
(
Page

)
POWERFUL Button
Press this button to start
powerful operation.
(
(
Page

)
Transmission Sign
Th
e
tra
ns
missio
n
sign blinks
when
a signal
has
bee
n
send.
ON/OFF Button
Press this button to start
operation.
Press it again to stop operation.
( Page
( Page

)
TEMPERATURE Button
Room temperature setting.
Value will change quic
k
er when
keep pressing.
(
Page 3)
FAN SPEED Button
Select the
f
an speed
f
or
cooling
and heating mode.
(
Page

)
UP/DOWN Button
Control the angle of the
horizontal air deflector.
(
(
Page

)
LEAVE HOME Button
(
Page

)
FROST WASH/CLEAN
Button
(
Page

)
- 2 -
8
