Hitachi RCUE100AG2 User Manual

SMGB0003 rev.0-01/2007
page 12
Product range and
specifications
1.1. General data for RCUE40~400AG2
MODEL RCUE40AG2 RCUE50AG2 RCUE60AG2 RCUE70AG2
Cooling Capacity
kW
112
130
156
178
Total Power input
kW
36.4
42.7
52.3
59.8
COP
-
3.08
3.04
2.98
2.98
Outer Dimension
Height
mm
2.430
2.430
2.430
2.430
Width
mm
1.900
1.900
1.900
1.900
Depth
mm
2.150
2.150
2.150
2.750
Cabinet colour
-
Natural Grey
Net weight
Kg
1.430
1.470
1.560
1.760
Compressor type
-
Semi-hermetic screw type
Models
-
40ASC-Z
40ASC-Z
50ASC-Z
60ASC-Z
Quantity
-
1
1
1
1
Oil heater
W
150
150
150
150
Capacity control
-
Continuous Capacity Control
%
15~100
Water cooler type
-
Brazing Plate Type
Condenser type
-
Multi-Pass cross fi nned tube
Fan Motor (pole)
kW
0.38 (8)
Quantity
-
4
4
4
6
Refrigerant type
-
R407C (Factory charged)
Flow control
-
Electronic expansion valve
Number of independent circuits
-
1
1
1
1
Quantity of refrigerant (kg)
-
39
46
41
48
Oil type
-
JAPAN ENERGY FREOL UX300 (Ester)
Water pipe connection
Inch
3” Victaulic (1xInlet/1xOutlet)
Control system
-
Micro-processor control
Chilled water outlet temperature
ºC
-10 (Option) 5~15
Condenser air inlet temperature
ºC
-15~46
Permissible water pressure max.
MPa
1.0
Safety and protection devices
-
Reverse Phase Protection, Fuse and Thermal Relay for Compressor,
Internal Thermostat for Compressor, Compressor Oil Heater,
Fuse and Internal Thermostat for Fan Motor, Control Circuit Fuse,
High Pressure Switch, Low Pressure Control,
High Pressure Relief Valve, Discharge Gas Temperature Control,
Suction Gas Temperature Control, Freeze Protection Control
and Compressor Operation Hour Meter
Power suply
-
3~, N/380-415V/50Hz

NOTE:
The nominal cooling capacities are based on the European Standard EN12055.
Chilled Water Inlet / Outlet Temperature : 12/7 °C
Condenser Inlet Air Temperature : 35 °C
−
−

Hitachi RCUE100AG2 Specifications

General

Brand	Hitachi
Model	RCUE100AG2
Category	Chiller
Language	English
