Hitachi SJ-P1 Series - Installation and Configuration

5-1
Chapter 5
Installation and Configuration
Contents
5.1 About this chapter ........................................... 5-1
5.2 Supported inverters ........................................ 5-2
5.3 Installation ........................................................ 5-2
5.3.1 About the installation .............................. 5-2
5.3.2 How to install ............................................ 5-3
5.4 Attach the ferrite cores ................................... 5-4
5.5 About the connection ..................................... 5-5
5.6 External features .............................................. 5-6
5.6.1 Ethernet connector specifications ......... 5-6
5.6.2 Ethernet cable specifications ................. 5-6
5.6.3 External power supply (optional) ........... 5-7
5.6.4 LED ............................................................. 5-7
5.7 System Configuration ..................................... 5-8
5.1 About this chapter
This chapter contains information for installing
and system configuring this device on the inverter.
For information about the inverter installation
please refer to the inverter user's guide.
Additionally, when doing any work or operation,
always follow the safety instructions and cautions
given in the chapter 1.
Symbol
Definition
Precautions
！
5
Chapter 5 Installation
and Configuration
