Introduction
This appendix lists the user-programmable parameters for the SJ100 series inverters and
the default values for European and U.S. product types. The right-most column of the
tables is blank, so you can record values you have changed from the default. This
involves just a few parameters for most applications. The two sections in this appendix
present the parameters in a format oriented toward two different programming devices:
• the keypad on the inverter, and
• the digital operator panel software (DOP Plus) for the PC
Please refer to the section corresponding to your preferred programming tool.
Parameter Settings for Keypad Entry
SJ100 series inverters provide many functions and parameters which can be configured
by the user. We recommend that you record all parameters which have been edited, in
order to help in troubleshooting or recovery from a loss of parameter data.
Main Profile Parameters
Inverter model
MFG. No.
SJ100
}
This information is printed
on the specification label
located on the right side of
the inverter.
“F” Group Parameters Default Setting
User Setting
Func. Code Name -FE (Europe) -FU (USA)
F01 Output frequency setting 0.0 0.0
F02 Acceleration 1 10.0 10.0
F202 Acceleration 1, 2nd motor 10.0 10.0
F03 Deceleration 1 10.0 10.0
F203 Deceleration 1, 2nd motor 10.0 10.0
F04 Running direction setting 0.0 0.0
To Next Page
