Parameter Settings for DOP/DRW/DOP Plus
Appendix B
B–16
F-35
Intelligent output 11
function code
OUT-TM 1 FA1 OUT-TM 1 FA1
Intelligent output 12
function code
OUT-TM 2 RUN OUT-TM 2 RUN
Relay output function
code
OUT-TM RY AL OUT-TM RY AL
Relay output NO/NC
(active state)
OUT-TM O/C-RY NC OUT-TM O/C-RY NC
Intelligent output 11
NO/NC (active state)
OUT-TM O/C-1 NO OUT-TM O/C-1 NO
Intelligent output 12
NO/NC (active state)
OUT-TM O/C-2 NO OUT-TM O/C-2 NO
F-36
Carrier frequency setting CARRIER 05.0kHz CARRIER 05.0kHz
F-37
Monitor signal selection MONITOR A-F MONITOR A-F
F-38
Initialization country
code for default settings
INIT SEL EUR INIT SEL USA
Debug mode display
selection
INIT DEBG OFF INIT DEBG OFF
Motor rotation direction INIT DOPE FWD INIT DOPE FWD
Initial mode selection INIT MODE TRP INIT MODE TRP
Cooling fan control
mode
INIT FAN-CTL OFF INIT FAN-CTL OFF
F-43
PID loop enable PID SW OFF PID SW OFF
PID proportional gain PID P 1.0 PID P 1.0
PID integral gain PID I 001.0s PID I 001.0s
PID derivative gain PID D 000.0 PID D 000.0
PID scale factor setting PID CONV 01.00 PID CONV 01.00
PID input (PV) selection PID INPT CUR PID INPT CUR
Function Mode Setup Displayed Default Setting
User Setting
Func.
Code
Name -FE (Europe) -FU (USA)
