SJ100 Inverter
Appendix B
B–15
F-32
Frequency arrival
threshold during
acceleration
ARV ACC 000.0Hz ARV ACC 000.0Hz
Frequency arrival
threshold during
deceleration
ARV DEC 000.0Hz ARV DEC 000.0Hz
F-33
Overload previous level OV Load 03.00A
(rated current)
OV Load 03.00A
(rated current)
Error overload (thresh-
old) for PID loop
OV PID 003.0% OV PID 003.0%
F-34
Intelligent input 1
function code
IN-TM 1 FW IN-TM 1 FW
Intelligent input 2
function code
IN-TM 2 RV IN-TM 2 RV
Intelligent input 3
function code
IN-TM 3 CF1 IN-TM 3 AT
Intelligent input 4
function code
IN-TM 4 CF2 IN-TM 4 USP
Intelligent input 5
function code
IN-TM 5 RS IN-TM 5 2CH
Intelligent input 6
function code
IN-TM 6 2CH IN-TM 6 RS
Intelligent input 1
NO/NC (active state)
IN-TM O/C-1 NO IN-TM O/C-1 NO
Intelligent input 2
NO/NC (active state)
IN-TM O/C-2 NO IN-TM O/C-2 NO
Intelligent input 3
NO/NC (active state)
IN-TM O/C-3 NO IN-TM O/C-3 NO
Intelligent input 14
NO/NC (active state)
IN-TM O/C-4 NO IN-TM O/C-4 NC
Intelligent input 5
NO/NC (active state)
IN-TM O/C-5 NO IN-TM O/C-5 NO
Intelligent input 6
NO/NC (active state)
IN-TM O/C-6 NO IN-TM O/C-6 NO
Function Mode Setup Displayed Default Setting
User Setting
Func.
Code
Name -FE (Europe) -FU (USA)
