Parameter Settings for DOP/DRW/DOP Plus
Appendix B
B–14
F-23
Electronic thermal cut-
off characteristic
E-THM CHAR CRT E-THM CHAR CRT
Electronic thermal cut-
off characteristic, 2nd
motor
2E-THMCHAR CRT E-THMCHAR CRT
Electronic thermal level E-THM LVL 03.00A
(rated output current)
E-THM LVL 03.00A
(rated output current)
Electronic thermal level,
2nd motor
2E-THMLVL 03.00A
(rated output current)
2E-THMLVL 03.00A
(rated output current)
F-24
Overload limit setting OLOAD LVL 03.75A
(rated current * 1.25A)
OLOAD LVL 03.75A
(rated current * 1.25A)
Overload limit constant OLOAD CONST 01.0 OLOAD CONST 01.0
Overload limit load OLOAD MODE ON OLOAD MODE ON
F-25
Software lock selection S-LOCK MD1 S-LOCK MD1
F-26
Frequency lower limit LIMIT L 000.0Hz LIMIT L 000.0Hz
Frequency upper limit LIMIT H 000.0Hz LIMIT H 000.0Hz
F-27
Jump frequency 1 JUMP F1 000.0Hz JUMP F1 000.0Hz
Jump frequency 2 JUMP F2 000.0Hz JUMP F2 000.0Hz
Jump frequency 3 JUMP F3 000.0Hz JUMP F3 000.0Hz
Jump frequency width
(hysteresis) 1
JUMP W1 00.5Hz JUMP W1 00.5Hz
Jump frequency width
(hysteresis) 3
JUMP W2 00.5Hz JUMP W2 00.5Hz
Jump frequency width
(hysteresis) 3
JUMP W3 00.5Hz JUMP W3 00.5Hz
F-28
Stop key enable during
terminal mode
STOP-SW ON STOP-SW ON
F-31
External frequency start
(output bias setting)
IN EXS 000.0Hz IN EXS 000.0Hz
External frequency end
(output span setting)
IN EXE 000.0Hz IN EXE 000.0Hz
External frequency start
(input bias
IN EX%S 000% IN EX%S 000%
External frequency start
(input span)
IN EX%E 100% IN EX%E 100%
External frequency start
point (input offset)
IN LEVEL 0Hz IN LEVEL 0Hz
External input filter time
constant
IN F-SAMP 8 IN F-SAMP 8
Function Mode Setup Displayed Default Setting
User Setting
Func.
Code
Name -FE (Europe) -FU (USA)
