SJ100 Inverter
Inverter Mounting
and Installation
2–9
Dimensional drawings continued...
FAN
MODEL
External Dimensions
SJ 100
-004HFE
-004HFU
-007NFE
-007NFU
98(3.86)
118(4.65)
5(0.20)
130(5.12)
5(0.20)
Air
Air
98(3.86)
118(4.65)
SJ 100 -007HFE(No fan)
-007HFU(No fan)
-015HFE
-015HFU
110(4.33)
4(0.16)
10(0.39)
7(0.28)
2.5(0.10)
129(5.08)
5(0.20)
110(4.33)
4(0.16)
5(0.20)
130(5.12)
6(0.24)
156(6.14)
7(0.28)
-011NFE
-022HFE
-022HFU
Ground Terminal
Ground Terminal
MODEL
