“C” Group: Intelligent Terminal Functions
Configuring
Drive Parameters
3–32
Output Terminal Configuration
The inverter provides configuration for logic (discrete) and analog outputs, shown in the
table below.
The output logic convention is programmable for terminals 11, 12, and the alarm relay
terminals. The open-collector output terminals 11 and 12 default to normally open
(active low), but you can select normally closed (active high) for terminal 11 in order to
invert the sense of the logic. The relay already has normally open and normally closed
contacts, but you can invert the logical sense of these as well.
“C” Function
Run-
time
Edit
Defaults DOP,DRW,DOP+
Func.
Code
Name Description
EU/
US
Units
Func.
Code
Name
C21 Terminal 11 function
(logical)
Select function for terminal 11,
6 options (see next section)
✘
01 — F-35 OUT-TM
1
C22 Terminal 12 function
(logical)
Select function for terminal 12,
6 options (see next section)
✘
00 — F-35 OUT-TM
2
C23 Terminal FM function
(analog)
Select function for terminal
FM, 3 options
(see next section)
✘
00 — F-37
MONITOR
C24 Alarm relay terminal
function (logical)
Select function for alarm
terminals
6 options (see next section)
✘
05 — F-35 OUT-TM
RY
“C” Function
Run-
time
Edit
Defaults DOP,DRW,DOP+
Func.
Code
Name Description
EU/
US
Units
Func.
Code
Name
C31 Reserved Factory use only; do not
change
✘
00 — F-35 OUT-TM
O/C-1
C32 Terminal 11 active
state
Select logic convention, two
option codes:
00...normally open [NO]
01...normally closed [NC]
✘
00 — F-35 OUT-TM
O/C-2
C33 Alarm relay active
state
Select logic convention, two
option codes:
00...normally open [NO]
01...normally closed [NC]
✘
01 — F-35 OUT-TM
O/C-RY
