Hitachi SJ300 Series

“B” Group: Fine-Tuning Functions
Configuring Drive
Parameters
3–38
Function
Code
Data
Resulting Non-displayed
Functions (when B37 = 01)
Notes
A044, A244 02 B100 – B113 Control methods
A051 01 A052 – A059 DC braking
A071 01 A072 – A076, C044 PID function
A094 01 A095 – A096 2-stage adjustable frequency
A294 01 A0295 – A296
B013, B213,
B313
02 B015 – B020 Electric thermal characteris-
tic
B021 01, 02 B022, B023 Overload restriction
B024 01, 02 B025, B026 Overload restriction 2
B095 01, 02 B090 – B096 Dynamic braking function
C001 – C008
06 A038, A039 Jogging
08
F202, F203, A203, A204, A220,
A241 – A244, A261, A262,
A292 – A296, B212, B213, H202
– H206, H220 – H224, H230 –
H234, H250 – H252, H260
2nd motor control
11 B088 Free-run stop
17 F302, F303, A303, A304, A320,
A342 – A344, A392, A393,
B312, B313, H306
3rd motor control
18 C102 Reset
27, 28, 29 C101 UP/DWN
A044
00, 01 A041 – A043 Torque boost function
04 H060 0Hz domain SLV limiter
A244
00, 01 A241 – A243 Torque boost function
04 H260 0Hz SLV limiter
A044
03, 04, 05 B040 – B046, H001, H070 –
H072, H002, H005, H020 –
H024, H030 – H034, H050 –
H052, H060
Vector control
A244
03, 04 B040 – B046, H001, H070 –
H072, H202, H205, H220 –
H224, H230 – H234, H250 –
H252, H260
Vector control
A097 01, 02, 03 A131 Acceleration pattern constant
A098 01, 02, 03 A132 Deceleration pattern constant
B098 01, 02 B099, C085 Thermistor function
B050 01 B051 – B054 Instantaneous power failure
B120 01 B121 – B126 External brake control
