Hitachi SJ300 Series

SJ300 Inverter
Configuring Drive
Parameters
3–67
“U” Group: User-selectable Menu Functions
The user-selectable menu functions allow you to configure (select) any twelve of the other
functions in the inverter and place them together in a convenient list. This feature provides
quick access for the most-used functions needed for your application. Each U Group function
can serve as a pointer to any of the other parameters. You do not have to use the Store key to
retain each association; just scroll to the desired standard parameter for each U Group function
and leave it. The setting can point to a monitor-only parameter (such as D001), or point to
editable parameters (such as A001). In the case of pointing to an editable functions, you use the
Up/Down keys to change the value and the Store key to accept the change into memory—the
same procedure as a normal parameter edit.
TIP: Function B037 selects which parameter groups are displayed. If you want to limit the
displayed parameters to only the U Group functions, set B037=02.
“U” Function
Run
Mode
Edit
Lo Hi
Defaults
Units
SRW Display
Func.
Code
Name Description
–FE
(EU)
–FU
(US)
–FR
(JP)
U001
User-selected function
“no” (disabled), or any of
the functions D001 to P049
✘ ✔ no no no —
>U001 USER
1 no
U002 ✘ ✔ no no no —
>U002 USER
2 no
U003 ✘ ✔ no no no —
>U003 USER
3 no
U004 ✘ ✔ no no no —
>U004 USER
4 no
U005 ✘ ✔ no no no —
>U005 USER
5 no
U006 ✘ ✔ no no no —
>U006 USER
6 no
U007 ✘ ✔ no no no —
>U007 USER
7 no
U008 ✘ ✔ no no no —
>U008 USER
8 no
U009 ✘ ✔ no no no —
>U009 USER
9 no
U010 ✘ ✔ no no no —
>U010 USER
10 no
U011 ✘ ✔ no no no —
>U011 USER
11 no
U012 ✘ ✔ no no no —
>U012 USER
12 no
