Hitachi SJ300 Series

“C” Group: Intelligent Terminal Functions
Configuring Drive
Parameters
3–58
C044 PID deviation level
setting
Sets the PID loop error
threshold |SP - PV|
(absolute value) to trigger
intelligent output [OD].
Range is 0.0 to 100%,
resolution is 0.1%
✘ ✔ 3.0 3.0 3.0 %
>C044 PID
LEVEL 003.0%
C045 Frequency arrival
setting for acceleration
(2)
Range is 0.0 to 99.99 /
100.0 to 400.0 Hz
✘ ✔ 0.00 0.00 0.00 Hz
>C045 ARV
ACC2 0000.00Hz
C046 Frequency arrival
setting for deceleration
(2)
Range is 0.0 to 99.99 /
100.0 to 400.0 Hz
✘ ✔ 0.00 0.00 0.00 Hz
>C046 ARV
DEC2 0000.00Hz
C055 Over-torque (forward-
driving) level setting
Threshold for intelligent
output terminal [OTQ],
quadrant I. Range is:
0 to 200%, up to –550xxx;
0 to 180%, –750 to 1500xxx
✘ ✔ 100. 100. 100. %
>C055 OV-TRQ
FW-V 100%
C056 Over-torque (reverse
regenerating) level
setting
Threshold for intelligent
output terminal [OTQ],
quadrant II. Range is:
0 to 200%, up to –550xxx;
0 to 180%, –750 to 1500xxx
✘ ✔ 100. 100. 100. %
>C056 OV-TRQ
RV-R 100%
C057 Over-torque (reverse
driving) level setting
Threshold for intelligent
output terminal [OTQ],
quadrant III. Range is:
0 to 200%, up to –550xxx;
0 to 180%, –750 to 1500xxx
✘ ✔ 100. 100. 100. %
>C057 OV-TRQ
RV-V 100%
C058 Over-torque (forward
regenerating) level
setting
Threshold for intelligent
output terminal [OTQ],
quadrant IV. Range is:
0 to 200%, up to –550xxx;
0 to 180%, –750 to 1500xxx
✘ ✔ 100. 100. 100. %
>C058 OV-TRQ
FW-R 100%
C061 Electronic thermal
warning level setting
Sets the threshold for intelli-
gent output [THM].
Range is 0 to 100%
✘ ✔ 80. 80. 80. %
>C061 E-THM
WARN 080%
C062 Alarm code output Allows binary alarm codes
to be output to intelligent
terminals.
Three option codes:
00 Disable
01 Enable – 3-bit code
02 Enable – 4-bit code
✘ ✔ 00 00 00 —
>C062 AL-CODE
SELECT OFF
C063 Zero speed detection
level
Range is 0.00 to 99.99 /
100.0 Hz
✘ ✔ 0.00 0.00 0.00 Hz
>C063 ZS
LEVEL 000.00Hz
“C” Function
Run
Mode
Edit
Lo Hi
Defaults
Units
SRW Display
Func.
Code
Name Description
–FE
(EU)
–FU
(US)
–FR
(JP)
