NOTE: Set frequency (speed) values are not permitted to be inside the jump frequency ranges,
if defined. When a frequency reference value from a real-time source (such as keypad potenti-
ometer or analog input) are inside a jump frequency range, the actual speed is automatically
forced to equal the lowest point of the jump range.
Programming Error
Code
Parameter out of bounds Boundary defined by...
Code Description <, > Code Description
091 291
A061 / A261 Frequency upper limit
setting; 1st, 2nd motor
> B112 Free-setting V/f frequency (7)
092 292
A062 / A262 Frequency lower limit
setting; 1st, 2nd motor
>
095 295
F001,
A020 / A220
Output frequency setting,
Multi-speed freq. setting;
1st, 2nd motor
>
096
A021 to A035 Multi-speed freq. settings >
110
B100, B102,
B104, B106,
B108, B110
Free V/f frequency >
B102, B104,
B106, B108,
B110
Free V/f frequency > B100 Free-setting V/f frequency (1)
B100 Free V/f frequency < B102 Free-setting V/f frequency (2)
B104, B106,
B108, B110
Free V/f frequency >
B100, B102 Free V/f frequency < B104 Free-setting V/f frequency (3)
B106, B108,
B110
Free V/f frequency >
B100, B102,
B104
Free V/f frequency < B106 Free-setting V/f frequency (4)
B108, B110 Free V/f frequency >
B100, B102,
B104, B106
Free V/f frequency < B108 Free-setting V/f frequency (5)
B110 Free V/f frequency >
B100, B102,
B104, B106,
B108
Free V/f frequency < B110 Free-setting V/f frequency (6)
120
B017, B019 Free-setting electronic
thermal frequency
< B015 Free-setting, electronic
thermal frequency (1)
B015 Free-setting electronic
thermal frequency
> B017 Free-setting, electronic
thermal frequency (2)
B019 Free-setting electronic
thermal frequency
<
B015, B017 Free-setting electronic
thermal frequency
> B019 Free-setting, electronic
thermal frequency (3)
