--- 23 ---
PARTS
VB 13Y
: ALTERNATIVE PARTS
ITEM
NO.
CODE NO. DESCRIPTION
NO.
USED
REMARKS
1 998-471 HEX. SOCKET HD. BOLT M5X12 2
2 316-224 WASHER 2
3 318-288 CENTER PLATE (A) 1
4 873-570 O-RING (P-18) 1
5 316-220 TURN TABLE 1
6 316-219 CAM COVER 1
7 316-216 FELT PACKING 1
8 316-199 CAM 1
9 939-540 RETAINING RING FOR D10 SHAFT (10 PCS.) 1
10 316-201 LOCK PIN (B) 1
11 316-198 V-RING 1
12 316-200 CAM SHAFT 1
13 316-184 INNER COVER ASS’Y 1 INCLUD.17,35,41,42
14 316-225 STAND 1
15 931-701 BEARING LOCK 1
16 316-195 HEX. SOCKET HD. BOLT (W/FLANGE) M5X20 2
17 630-1VV BALL BEARING 6301VVCMPS2L 1
18 316-202 FINAL GEAR 1
19 965-469 RETAINING RING FOR D25 SHAFT 1
20 620-1VV BALL BEARING 6201VVCMPS2L 1
21 316-451 PIN D18 1
22 316-211 GEAR COVER ASS’Y 1 INCLUD.20,21,46,49
23 318-284 SENSOR HOLDER ASS’Y 1 INCLUD.24,56
24 316-214 TAPPING SCREW D3X12 1
25 949-215 MACHINE SCREW M4X8 (10 PCS.) 2
26 316-212 SENSOR GEAR 1
27 985-227 O-RING (S-85) 1
28 316-215 SENSOR COVER 1
29 994-192 HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 9
30 316-223 ROLLER (B) 1
31 318-287 LEVER (A) 1
32 949-322 FLAT HD. SCREW M4X10 (10 PCS.) 5
33 316-217 FELT PACKING 1
34 306-506 FEATHER KEY 7X7X15 4
35 316-186 SUPPORT (B) 1
36 987-203 SEAL LOCK SCREW (W/SP. WASHER) M4X12 2
37 875-249 THRUST WASHER 1
38 316-197 RETURN SPRING 1
39 316-196 FLANGE NUT M12 1
40 307-607 WRENCH HOLDER 1
41 316-185 METAL 1
42 954-940 METAL D8X10 1
43 316-203 THIRD PINION 1
44 948-015 FEATHER KEY 5X5X10 1
45 316-204 THIRD GEAR 1
46 954-789 METAL (B) 1
47 316-205 SECOND PINION 1
48 316-206 SECOND GEAR 1
49 608-VVM BALL BEARING 608VVC2PS2L 2
50 318-360 SLEEVE (B) 1
51 318-358 FIRST GEAR (B) 1
*
9
---
99
