PARTS
VB 13Y
ITEM
NO.
CODE NO. DESCRIPTION
NO.
USED
REMARKS
52 316-209 CLUTCH SPRING 1
53 316-208 COLLAR (A) 1
54 981-077 WASHER 1
55 318-359 FIRST PINION (B) 1
56 316-212 SENSOR GEAR 1
57 962-569 WASHER (B) 1
58 316-228 HEX. SOCKET HD. BOLT (W/FLANGE) M4X10 2
59 316-226 STEEL BAR GUIDE 1
60 316-190 NEEDLE 1
61 992-805 RETAINING RING FOR D9 SHAFT 1
62 316-189 ROLLER (C) 1
63 318-285 COVER 1
64 980-879 O-RING (S-34) 1
65 316-194 BOLT (A) 1
66 980-809 FEATHER KEY 4X4X8 1
67 949-821 HEX. SOCKET HD. BOLT M5X16 (10 PCS.) 2
68 316-188 BRACKET (A) 1
69 316-235 CUTTER (1 PAIR) 2
70 316-191 CUTTER GUARD 1
71 316-192 SPRING (C) 1
72 316-193 PIN FOR SPRING 1
73 316-187 BRACKET (B) 1
74 316-222 DUST GUARD 1
75 938-477 HEX. SOCKET SET SCREW M5X8 2
76 935-829 BRUSH CAP 2
77 999-043 CARBON BRUSH (1 PAIR) 2
78 971-001 BRUSH HOLDER 2
79 313-585 HEX. SOCKET HD. BOLT (W/FLANGE) M5X30 4
80 318-286 CAUTION PLATE (E) 1
81 301-653 TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 6
82 316-227 TAIL COVER 1
83 310-111 BEARING BUSHING (B) 1
84 318-362 BALL BEARING (A) 2
85 HITACHI LABEL 1
86 310-146 HOUSING ASS’Y 1 INCLUD.75,78
87 930-703 BRUSH TERMINAL 2
88 340-419E STATOR ASS’Y 230V 1 INCLUD.87
89 990-861 INTERNAL WIRE 1
90 980-864 HEX. HD. TAPPING SCREW D5X40 2
91 980-931 FAN GUIDE 1
92 360-470E ARMATURE 230V 1
93 NAME PLATE 1
94 316-234 HANDLE (A).(B) SET 1
95 318-282 CONTROLLER CIRCUIT 1
96 318-283 INTERNAL WIRE 1
97 981-373 TUBE (D) 1
98 959-140 CONNECTOR 50091 (10 PCS.) 7
99 878-609 O-RING (S-24) 1
100 318-281 VOLUME HOLDER ASS’Y 1 INCLUD.99
101 318-289 CAUTION PLATE (D) 1
: ALTERNATIVE PARTS
*
