Model
Drive
count
Unit
size
(U) Path
Number of drive tray
connections
Maximum
number
of drives
1
Maximum
number of
drives per
pathLFF SFF
FM
D
Dense
intermix
VSP
G700
— 4 2 36 36 36 20 1200 600
VSP
G900
— 4 4
2
24 24 24 24 1440 360
— 4 8
3
48 48 48 24 1440 360
Notes:
1. The maximum number of drives may be limited depending on the mounting
pattern when LFF
, SFF, FMD, or dense intermix drive trays are used together.
2. For a VSP G900, the following values apply when the DKB option is set to OFF.
3. For a VSP G900, the following values apply when the DKB option is set to OFF.
Model
Drive
count
Unit size
(U) Path
Number of FMD
drive tray
connections
Maximu
m
number
of
drives
Maximu
m
number
of
drives
per pathDBS FMD
VSP
F350
SFF: 24 2 1 7 N/A 192 192
VSP
F370
SFF: 24 2 1 11 N/A 288 288
VSP
F700
— 4 2 36 36 864 432
VSP
F900
— 4 4
1
24 24 1152 288
— 4 8
2
48 48 1152 144
Notes:
1. For a VSP F900
, the following values apply when the DKB option is set to OFF.
2. For a VSP F900, the following values apply when the DKB option is set to OFF.
Drive tray specications
Chapter 1: Installation site considerations
Site Preparation Guide for VSP G/F350, G/F370, G/F700, G/F900 16
