General Maintenance - 52 -
TAPE DISPLAY
Symptom Check Point & Correction
TAPE appears in the viewfinder § Have you moved the camcorder or
cassette from a cold place to a
warm place so that its temperature
changed abruptly?
§ If the temperature has changed,
remove the cassette and set the
CAM/OFF/VIDEO switch to OFF,
then wait for about one hour.
§ Remove the cassette and then try to
reinsert: remove it several times.
§ If the indication is still shown in the
viewfinder, use a cleaning tape to
clean the heads and replace the
cassette.
Specifications
General Specifications
Power requirements 6V DC
Power consumption 5.1W (when recording/LCD monitor OFF)
7.3W (when recording/LCD monitor ON)
Dimensions 4-5/8" W x 4-3/4" H x 8-5/16" D (118mm x 120mm x 211mm)
Weight 2.31 lbs (approx. 1050g) without battery pack, lens
lens cap or cassette
Operating temperature 32°F ~ 104°F (0°C ~ 40°C)
Storage temperature -4°F ~ 140°F (-20°C ~ 60°C)
Video Recorder Specifications
Format 8mm
Record/playback Two video record/playback heads
Video signal EIA standard NTSC color
Tape speed 14.3mm/sec
Video input 1.0Vp-p, 75 ohm
Video output 1.0Vp-p, 75 ohm
Audio input -7.8dBs (316mVrms)
Audio output -7.8dBs (316mVrms)
Fast forward/rewind time Less than 8 minutes with P6-120 cassette
Camera Specifications
Scanning 525 lines/60 fields/30 frames
Required minimum illumination 1 lux
Pickup device 1/4" C.C.D.
Lens diameter 46mm
For U.S.A. only
HITACHI
Service Hotline
To locate an authorized
HITACHI service facility
