Number Item
3 Clip
8. Attach the side bezel to the left and right sides of the rack by sliding the bezels in place.
Step 5: Cable the drive boxes
The drive boxes must be cabled to the controller exactly how they were configured before shipping.
The drive boxes and controllers are shipped pre-configured and must be cabled according to the following cable
diagram.
Procedure
