Hitachi WJ200 Series - Page 74

Appendix PROFINET Object List
68
Index
Sub-
index
Register
number
Size
[bite]
Function
code
Name
R/W
Description and range
Resolution
WJ200
only
1000
0x3C
0x003B
02
(UINT)
d085
Trip
information
5 (inverter
status)
R
Please refer to section
9, status code list
-
2000
0x3D
0x003C
04
(UDINT)
d085
Trip
information
5
(frequency)
R
Output frequency at
trip point
0.01[Hz]
1000
0x3F
0x003E
02
(UINT)
d085
Trip
information
5 (current)
R
Motor current at trip
point
0.01[A]
1000
0x40
0x003F
02
(UINT)
d085
Trip
information
5 (voltage)
R
DC bus voltage at trip
point
0.1[V]
2000
0x41
0x0040
04
(UDINT)
d085
Trip
information
5 (running
time)
R
Cumulative inverter
operation time at trip
point
1[h]
2000
0x43
0x0042
04
(UDINT)
d085
Trip
information
5 (power-on
time)
R
Cumulative power-ON
time at trip point
1[h]
1000
0x45
0x0044
02
(UINT)
d086
Trip
information
6 (factor)
R
Please refer to section
9, factor code list
-
1000
0x46
0x0045
02
(UINT)
d086
Trip
information
6 (inverter
status)
R
Please refer to section
9, status code list
-
2000
0x47
0x0046
04
(UDINT)
d086
Trip
information
6
(frequency)
R
Output frequency at
trip point
0.01[Hz]
1000
0x49
0x0048
02
(UINT)
d086
Trip
information
6 (current)
R
Motor current at trip
point
0.01[A]
1000
0x4A
0x0049
02
(UINT)
d086
Trip
information
6 (voltage)
R
DC bus voltage at trip
point
0.1[V]
2000
0x4B
0x004A
04
(UDINT)
d086
Trip
information
6 (running
time)
R
Cumulative inverter
operation time at trip
point
1[h]
