34
PMEN0645 rev.0 - 04/2023
6
GENERAL CHECK
ELECTRICAL AND CONTROL SETTINGS
6.1 General check
• Make sure that the following condions related to power supply installaon are sased:
✓ The power capacity of the electrical installaon is large enough to support the power
demand of the YUTAKI system (outdoor unit + indoor unit + DHW tank (if apply)).
✓ The power supply voltage is within ±10% of the rated voltage.
✓ The impedance of the power supply line is low enough to avoid any voltage drop of more
than 15% of the rated voltage.
• Following the Council Direcve 2004/108/EC, relang to electromagnec compability, the
table below indicates the Maximum permied system impedance Z
max
at the interface point of
the user’s supply, in accordance with EN61000‑3‑11.
Model Power supply Operaon mode Z
(Ω)
RWD‑(1.5‑3.0)RW2E‑220S(‑K)
~ 230V 50Hz
Without electric heaters
‑
With electric heater
‑
With DHW tank heater
‑
With electric and DHW tank heaters
0.30
3N~ 400V 50Hz
Without electric heaters
‑
With electric heater
‑
With DHW tank heater
‑
With electric and DHW tank heaters
‑
RWD‑(2.0‑3.0)RW2E‑220S‑6H
~ 230V 50Hz
Without electric heaters
‑
With electric heater
0.28
With DHW tank heater
‑
With electric and DHW tank heaters
0.20
3N~ 400V 50Hz
Without electric heaters
‑
With electric heater
‑
With DHW tank heater
‑
With electric and DHW tank heaters
‑
• The status of Harmonics for each model, regarding compliance with IEC 61000‑3‑2 and
IEC 61000‑3‑12, is as follows:
Status regarding compliance with IEC 61000‑3‑2 and IEC 61000‑3‑12
Models
YUTAKI S Combi
Equipment complying with IEC 61000‑3‑2 (*): Professional use
Equipment complying with IEC 61000‑3‑12
tbc
Installaon restricons may be applied by supply authories in relaon to harmonics
