SETTINGOFDIPSWITCHESANDRSWSWITCHES
ELECTRICAL AND CONTROL SETTINGS
◆ DSW1: Addional seng 0
Factory seng. No seng is required.
DSW1
YUTAKI S Combi (*)
 NOTE
(*): In case of installing the “Cooling kit” accessory, set the pin 4 of DSW1 to ON in order to enable
the cooling operaon.
◆ DSW2: Unit capacity seng
Factory seng. No seng is required.
DSW2
1.5 HP 2.0HP 2.5HP 3.0HP
◆ DSW3: Addional seng 1
DSW3
Seng before shipment
1‑step heater for 3‑phase unit
◆ DSW4: Addional seng 2
DSW4
Seng before shipment
8
7
DHW defrost
8
7
Heater forced OFF
8
7
