Hitachi YUTAKI S COMBI Series Installation And Operation Manual

46
PMEN0645 rev.0 - 04/2023
6
TERMINALBOARDCONNECTIONS
ELECTRICAL AND CONTROL SETTINGS
Mark
Part name
Descripon
18 Input 4 (Solar) (*) Available input for Solar combinaon with Domesc Hot Water Tank.
19 Input 5 (Smart funcon) (*)
For the connecon of an external tari switch device to switch OFF the
heat pump during peak electricity demand period. Depending on the
seng, the heat pump or DHWT will be blocked when signal is open/
closed.
20
Input 6 (DHW boost) (*)
Available input for an instantaneous heang of the domesc hot water of
the tank.
21 Input 7 (Power meter)
The measuring of the real power consumpon can be done connecng
an external power meter. The number of pulses of the power meter is
a variable which must be set. By this, every pulse input is added into
corresponding operaon mode (Heang, Cooling, DHW Operaon). Two
possible opons:
‑ One power meter for all installaon (IU+OU).
‑ Two separated power meters (one for IU and one for OU).
22
Aquastat security for circuit 1
(WP1)
Terminals intended for the connecon of the Aquastat security accessory
(ATW‑AQT‑01) for controlling water temperature of the circuit 1.
23
24(C) Mixing valve close
When a mixing system is required for a second temperature control, these
outputs are necessary to control the mixing valve.
25(O) Mixing valve open
26(N) N Common
27(L) Water Pump 2 (WP2)
When there is a second temperature applicaon, a secondary pump is the
circulang pump for the secondary heang circuit.
28
Auxiliary power Power supply for ATW‑RTU and central device
29
30(N)
Electrical Heater DHW Output
If DHW tank contains an electric heater, the air to water heat pump
can acvate it if the heat pump cannot achieve the required DHW
temperature by itself.
31(L)
32 Output 9
33(L) L common Power supply for valve accessories
34(N)
N common Neutral terminal common for outputs 1, 2 and 9.
35(L)
Output 1 (3‑way valve for
swimming pool) (*)
The air to water heat pump can be use to heat swimming pool. This
output will be ON when swimming pool is acvated.
36(L)
Output 2
(Water pump 3 (WP3)) (*)
When there is a hydraulic separator or buer tank, addional water pump
(WP3) is needed.
37
Output 3 (Auxiliary boiler or
electric heater) (*)
The boiler can be used to alternate with the heat pump when the heat
pump cannot achieve the required temperature by itself.
A water electric heater (as accessory) can be used to provide the
addional heang required on the coldest days of the year.
38
39
Output 4 (Solar) (*) Output for solar combinaon with Domesc Hot Water Tank.
40
 NOTE
(*): Inputs and outputs explained in the table are the factory-set opons. By means of the unit
controller, some other inputs and outputs funcons can be congured and used. Please, refer to the
Service Manual for detailed informaon.
