Insert distance bars
Use carrier board from
assembly kit
Screw the carrier board
For Duplex TU module fixation, it is recommended to use parts from assembly kit HE7.
Use two longer distance bars and screw the carrier board . Insert remaining distance bars
for mounting Duplex TU module.
