Professional Balance Charger, Discharger
Hochleistungs Profi Balance
LADER / ENTLADER
Ventilation Fan
Universal Balancing Port
(Port Pitch 2,54 mm)
Universal Balancing Port
(Port Pitch 2,54 mm)
Input
11-30 V
Battery Socket
Temp Sensor/PC Link
Ventilation Fan
LCD Screen
Menu Control Buttons
LCD Screen
Menu Control Buttons
USB Port
Battery Socket
Temp Sensor/PC Link
USB Port
2.2. Charger Layout
