Hitron CODA-551x User’s Guide
1.3 LEDs
This section describes the CODA-551x’s LEDs (lights).
WAN Port The Wan-port is the uplink port of your device that uses
to connect to the wide area network such as Internet or
the modem that your ISP has provided.
LAN 1
Use these ports to connect your computers and other
network devices, using Category 5 or 6 Ethernet cables
with RJ45 connectors.
Each LAN port’s yellow LED glows when the connection
on the relevant port’s is at 1Gbps, and its green LED
glows when the connection is at 10/100Mbps.
LAN 2
POWER Use the POWER port to connect to the input
100~125VAC, output 12v, 5A power adapter that came
with your CODA-551x
Figure 3: Power Cable
Table 3: LEDs
COLOR STATUS STATE
Green Slow Blank Booting
White/Green alternating Establishing DOCSIS
White Slow Blink Provsioning
Table 2: Hardware Connections
