User Manual - CODA - Cable Modem6
Chapter 1 Hardware Overview
You can use the LEDs to verify status and connections. The following
table lists and describes each LED on the front panel of the cable
modem.
LED STATUS DESCRIPTION
LAN Off No device is connected to either of the LAN ports.
Green, Steady A device is connected to one or more of the LAN
ports, via an Ethernet (10/100/1000Mbps) link.
Online Green, Blinking The CODA cable modem is registering with the
service provider’s CMTS.
Green, Steady The CODA cable modem has successfully registered
with the service provider and is ready for data
transfer.
Off The CODA cable modem is offline.
Upstream Green, blinking The CODA is searching for an upstream frequency on
the CABLE connection.
Green, steady The CODA has successfully located and locked onto
a single upstream frequency on the CABLE
connection.
Blue, steady The CODA is successfully engaged in channel
bonding on the upstream connection.
Off There is no upstream activity on the CABLE
connection.
Downstream Green, blinking The CODA is searching for a downstream frequency
on the CABLE connection.
Green, steady The CODA has successfully located and locked
onto a single downstream frequency on the CABLE
connection.
Blue, steady The CODA is successfully engaged in channel
bonding on the downstream connection.
Off There is no downstream activity on the CABLE
connection.
Power Green, steady The CODA is receiving power.
Off The CODA is not receiving power.
