15
REPAIRS
RELAY BYPASS
WARNING: Before making repairs, be sure ON/OFF switch is OFF and
machine is unplugged!
ATTENTION: Eteindre la machine avant de faire des réparations.
1. Remove the back cover of the machine.
WARNING: To prevent posible electrical shock, unplug the machine
before removing cover to service.
ATTENTION: An d’éviter des choques électriques, éteindre la machine
avant d’ouvir.
2. Remove wire #26 from terminal #2 on relay.
3. Loosen terminal #1 on relay and replace wire #26 along with wire #12
under terminal #1.
4. Tighten the connection.
5. Plug machine in and turn the power switch on.
NOTE: Replace the relay if the machine starts heating. This is a test only.
Do not operate machine with relay bypassed.
LUBRICATION
Every 6 months add one to two drops of 3-in-1 oil (available at hardware
stores), to the joints of all moving parts.
CLEANING HEAT PLATEN
Clean the heat platen with steel wool, scrubbing aluminum sponge, or ne
wire brush.
MAINTENANCE
