Connect wires according to the enclosed wiring diaphragm
Move the valve manually to an half-open position, perform an electrical
OPEN operation and check that the motor rotates in the right direction
Standard units are counter-clockwise to open set
Test the actuator and check the limit switches work correctly
Check that all cable glands are correctly tighten
Applicable cable glands should be selected to meet the application conditions.
In potentially explosive environments, cable gland grades exceeding IP67 are
recommended. When fitting the cover, verify that the O-rings are in working condition
before operations.
Mount cover and tighten cover bolts
Cable Entry 1½
½½
½”:1EA
To Next Page
