MULTI-TURN ELECTRIC ACTUATOR ORDER CODING SYSTEM
HM-
 NOTE
Asterisk *1) According to high-speed operation can cause problems.Must connect to the Gearbox
More detail should be advised to the manufacturer.
A
B
C
D
E
F
XXX X X X X X
SIZE
A
004 HM-004
008 HM-008
011 HM-011
020 HM-020
040 HM-040
060 HM-060
100 HM-100
150 HM-150
200 HM-200
300 HM-300
B
ENCLOSURE
1 Weather proof(IP67)
2 Watertight(IP68)
3 EX type
C
MOTOR VOLTAGE
1 110V AC / 1PH (Only HM-008,020)
2 220V AC / 1PH (Only HM-040)
3 220V AC / 3PH
4 380V AC / 3PH
5 440V AC / 3PH
6 460V AC / 3PH
7 480~600V AC / 3PH
D
RPM
1 18/21 (50Hz/60Hz)
2 24/29 “
3 36/43 “
4 48/57 “
5 72/86 “
6 96/115 “
7 114/173 “ *1
8 192/230 “ *1
E
OPTION 1
0 N/A
1 PCU - Proportional Control Unit(Input,Output 0~10VDC, 4~20mA DC)
2 AMS1 – Additional monitoring switches(SPSTx4EA 250V AC 16A Rating)
3 CPT – Current Position Transmitter(Output 4~20mA DC)
4 MODBUS – Modbus Modules
5 PROFIBUS – Profibus DP Interface Module
F
OPTION 2 (Cable entry size)
1 PF1”x4EA, PF1 1/2”x1EA
2 NPT1”x4EA, NPT1 1/2”x1EA (Only EX type)
3 M33(2.0P)x4EA, M45(2.0P)x1EA (Only EX type)
