HKC HQ Series User Manual

HQ Series Quarter-turn Electric Actuator
Installation Operation& Maintenance Manual
Doc No. : HumG-HQ-21 Rev2 Page 6 / 26 Valve Automation Leader, HKC
3.1.4. Optional technical data
EX
D
Flame
proof enclosure
IECEx, ATEX, CSA, KCs
, [EAC
-----
20
Rev0]
EXTB
Dust Ignition proof enclosure IECEx, ATEX, KCs
, [EAC
-----
20
Rev0]
WTA
Watertight enclosure (IP68 10m / 72hr)
PIU
Potentiometer unit (0~1KΩ)
PCU
Proportional
control unit (input, output 0~10 V
dc
, 4~20mA
dc
)
ATS
Additional torque switches (SPDT X 2
ea
250V
ac
16A Rating)
SICU
[
Semi
-
Integral control unit(LCU
-
B
+IMS+phase protect indicator)
(5W max)
ICU
Intelligent
d
igital control unit(LCU
-
C
+IMS+auto phase
discriminator)
(5W max)
–
1
8
Rev
1
]
CPT
Current position transmitter(output 4~20mA
dc
)
EXT
Extension 120°,180°, 270° turn
ALS
Additional limit switches (SPDT X 2
ea
,
250 V
ac
,
16A Rating)
LPA
Lever plate actuator
SLU
Signal lamp unit(white: power on,
red: open, green: close, yellow: over torque)
[PRB
Profibus ( 5 V dc, 0.1 A max, if redundancy is multiply 2 )
MOB
Modbus (5 V dc, 0.1 A max, if redundancy is multiply 2 )
---
18 Rev1]
FPA1
Fire proofing actuator
, 50 minutes at
1
,
050 ± 5
℃
FPA2
Fire
proofing actuator
, 150 minutes
at
250 ± 5
℃
3.1.5. Duty Cycle *
1
[Duty cycle data were indicated Clause 3.1.1 Standard Technical Data.--- 16 Rev1]
Exceeding the actuator’s rated duty cycle may cause thermal overload.
Note *1 Type of duty according to VDE 0530 / IEC 60034-1
Short – time duty S2 Intermittent duty S4
The operation time at a constant load is
short, so that thermal equilibrium is not
reached. The pause is long enough for the
machine to cool down to ambient
temperature. [Example, the duration of the
short –time operation is limited to 15min ----
--- 15 Rev0]
The duty is a sequence of identical cyc
l
es which
consist of starting time, operation time with
constant load and rest period. The rest period
allows the machine to cool down so that thermal
equilibrium is not reached. [Example, the relative
on-time at S4-25% or S4-50% is limited to 25% and
50% respectively. ----- 15 Rev0]
3.1.6. Space Heater
Condensation in the actuator is possible due to wide fluctuation of the ambient temperature. The
heater integrated in the control unit prevents from this in general.
Ceramic housing with thermostat to prevent over heating with 60℃ set temperature.
Heating Element
Self
-
regulating
Voltage Range (HQ
-
008~010)
(based on the control power)
110 V
ac
5W
4.5
k
ΩJ
220 V
ac
5W 18
k
ΩJ
24 V
dc
5W 200ΩJ
12 V
dc
[
5W
56
ΩJ
---
21 Rev
1
]
Voltage Range (HQ
-
015~300)
(based on the control power)
110 V
ac
10W 2
k
ΩJ
220 V
ac
10W 8
k
ΩJ
24 V
dc
10W 100ΩJ
12 V
dc
10W 27ΩJ
[Note: Heaters of above were corrected from 2W. The heaters are regulated automatically up to
no-condensation point in enclosures only. Because there are not affected to explosion proof
performance. ------- 15 Rev0]
