HKS EVC - Mounting of Components; ５. Post Installation

−24−
４．MountingofComponents
ＥＶＣDisplayUnit(Rear)
(１)Removeanydirt,dustand/oroilfromthe
areatheunitisgoingtobemountedto.
(２)Securethedisplayunitusingtheincluded
double‑sidetape.
Advice
・Thedisplaywasdesignedtohavethebest
visibilitywhenitislookedatdownward.
Itisrecommendedtomountthedisplayunit
toapositionwhereitislowerthanyour
eyesormounttheunitfacingupwards.
４．１．MountingtheDisplayUnit
４．２．MountingtheSteppingMotor
４．３．SecuringtheHoseandHarness
５.PostInstallation
(１)MounttheSteppingMotorusingtheM6
boltandnut.
(１)Reinstallallremovedfactoryparts.
(２)Reconnectthenegativebatterycabletothebatteryterminal.
(１)Securehosesandharnessesusingtheincludedtie‑wraps.
Nipple
ＥＶＣSteppingMotor
Ｍ６
Advice
・Leaveslackinthehoseandharnesstoabsorbenginevibrationandmovement.
Advice
・Ruboffanypaintand/orrustofthesurfacewherethegroundwireisconnected.
(８)Connectthe4PINConnectoroftheMainHarnesstothePowerHarness.
Note
・WhenutilizinganexternalswitchfortheScrambleBoostactivation,connectthe
twowires(blueandwhite)ofthescrambleharnesstoamomentaryswitchinthe
formthatwhentheswitchistriggeredaclosed‑circuitismade.
Double‑StickTape
