HKS EVC - Poppet Valve Type

(３)Connectthe6mmVacuumFilteroftheEVC
SteppingMotor'sNippleⅠtotheT‑Fitting
usingthe6mmhose.
 Advice
・Donotputanyoiland/orlubricantson
orinthehoseorvacuumfilter.
(１)Cutthe8mmhoseatthepointof5cmfrom
thecompressor'sNipple①.Removethe
remaining8mmhoseand8mmnipplefromthe
wastegate.
 Note
・ThepositionofNipple①onthecompressor
mayvarydependingonthevehicle.
−19−
Nipple①
Nipple①
NippleⅠ
CutHere
5cmLength
Wastegate
6x8x6mmT‑Fitting
6mmVacuumFilter
6mmHose
6mmHose
6mmNipple
HoseClamp
Hose
Clamp
HoseClamp
Note
・Usethehoseclamptoconnectthe6mmhoseandthe6mmnipple.
(４)Afterremovingthe8mmnipplefromthe
wastegate,installthe6mmnipple(straight
orL‑Shaped).
(５)Installtheincluded6mmhoseasshownin
thediagramontheleft.
(２)Installthe6x8x6mmT‑Fittingusingthe8mm
HoseClamp.
 Note
・Usethe6x8x6mmT‑Fittingand8mmHose
Clampincludedinthehosekitforthe
poppetvalvetypeapplications.
