HKS EVC - Installation Guide; Preparation and Hose Connections

−12−
Installation
(１)Disconnectthenegativeterminalfromthebattery.
●Thismanualshowsatypicalinstallation.Actualinstallationmayvarydependingon
thevehicleapplication.
１．RemovalofBatteryTerminal
２．HoseConnectionLayout
(１)Withconsiderationtothehoseandharnesslengths,determinetheappropriatehose
connectionlayoutandmountinginregardstothedisplayunitandsteppingmotor.
Advice
・Leavesomeslackfortheharness&hosestoavoidtensionduringenginemovement.
・Donotinstallanycomponentsinhightemperatureareas.
●ThisproductwasdesignedtobeusedwithvehiclesusingaＤＣ１２Ｖ
negativeground.Donotuseonavehilcewitha２４Ｖground.
Warning
１.RemovalofBatteryTerminal……………………………………………………………………12
２.HoseConnectionLayout
２.１.Steppingmotorand4mmHose……………………………………………………………  13
２.２.SwingValveType…………………………………………………………………………14
２.３.PoppetValveType…………………………………………………………………………18
 ２.４.TwinTurbo（SwingValve）………………………………………………………………20
 ２.５.4mmHoseConnectionLayout（SwingValve）…………………………………………  21
３.Wiring………………………………………………………………………………………………23
４.MountingofComponents……………………………………………………………………………24
５.PostInstallation…………………………………………………………………………………24
