HKS EVC - Features and Functions; Unit Controls and Display Elements

−９−
FeaturesandFunctions
１.Features
１．Button①
Usethisbuttontoactivatethescramblefunctioninthestandardmode.Whilepressing
thisbutton,thescramblefunctionisactivated.Whenthescramblefunction'stimeris
set,thefunctionstartsworkingwhenthebuttonisreleased.Ifthesetvalueisblinking
inthespeedaxissetmode,RPMaxissetmode,throttleaxissetmode,mapcorrection
boostA/Bsetmode,ormapoffsetA/Bsetmode,thisbuttonisusedtoselectbetweenthe
setaxisandthesetvalue.
２．VolumeKnob
Inthestandardmode,pressingthevolumeknobformorethan1secondresetsthepeak
value.TurntheknoblefttoswitchtoboostmodeAandturnrighttothemodeB.
Pressingthevolumebuttonineachmodemakesthesetvalueblinkorturniton.When
thesetvalueisblinking,turningthevolumeknobtotherightincreasesthevalue;and
turningittotheleftdecreasesthevalue.Inothermodes(asidefromstandardmode),
whenthevalueisblinking,turningthebuttonswitchesthemodesineachmodegroup.
３．Button②
Inthestandardmode(whentheA/Bboostvalueisnotbeingset)pressthisbuttonfor
morethan1secondtoswitchtheEVConoroff.Whenthepowerison,theEVCcontrol
becomesactive.Whenthepowerisoff,thevehiclereturnstothestandardboostvalue
whichisnotcontrolledbytheEVC.Whenthesetvalueineachmodeisblinking,
pressingthisbuttonswitchesthemodegroup.
４．MainHarnessConnector
Thismainharnessconnectsthepowerharness,extensionharness,andeachsignalharness.
５．ScrambleHarnessConnector
Thisscrambleharnessconnectstheoptionalexternalscrambleswitch.
６．EasyWriterConnector
ThisconnectorisforPCcommunicationtomakesettingswiththeHKSEasyWriter.(Optional)
１．Button①
２．VolumeKnob
３．Button②
６．EasyWriterConnector（５PIN）
４．MainHarnessConnector（３PIN）
５．ScrambleHarnessConnector（２PIN）
Rear
Panel
Front
Panel
