−10−
１．DigitalDisplay（S）
Inthisdisplay,thepresetwarningvalue,presetA/Bboostvalues,scramble
countdowntime,modename,orwastegatetypeisshown.Thepressureisshownas
○○○(kPa)or○○.○(PSI),thescramblecountdowntimeisshownas○○(Sec),the
modenameisshownas○○○(MODE),andthewastegatetypeisshownas−○−.
StandardMode ：SetWarningValue
StandardMode(Ａ/ＢBoostSettings) ：PresetＡ/ＢBoostValues
StandardMode(ScrambleFunction) ：
ScrambleCountdownTime
EachSettingMode ：
ModeName
OpeningScreen ：
WastegateType
２．Speed/RPMDisplay
Inthisdisplay,thevalueforeachaxisofthefollowingmodeisshown;SpeedAxis
SetMode,RPMAxisSetMode,MapCorrectionBoostA/BSetModeandMapOffsetA/B
SetMode.
３．ThrottleDisplay
Inthisdisplay,thevalueforeachaxisofthefollowingmodeisshown;ThrottleAxis
SetMode,MapCorrectionBoostA/BSetMode,andMapOffsetA/BSetMode.
４．UnitDisplay
Inthisdisplay,the4unitsofmeasure(kPa,PSI,S,V)areshownforeachmode:
kPaisdisplayedformanifoldpressure
PSIisdisplayedformanifoldpressure
SisdisplayedintheScrambleTimeSetMode
VisdisplayedintheFullThrottleVoltageSet&ClosedThrottleVoltageSetModes
５．DigitalDisplay(L)
Inthisdisplay,themanifoldpressure,setvalue,ornameisshownas○○○(kPa)or
○○.○(PSI):
IntheStandardModetheboostvalueisshown
IneachSetMode,thesetvalueormodenameisshown
６．IndicatorDisplay
Thisdisplayshowsthefollowing:
IntheStandardModeandthepeakvalueisdisplayed,"P.H."isiluminated.
IntheStandardModeandthemapfunctionisbeingusedorintheMapSet
Group,"MAP"isiluminated.
Ineachmodewherethesetvalueisbeingchanged,"SET"isilluminated.
Ineachmodewherethesetvalueisbeingselected,"SEL"isilluminated.
IntheScrambleBoostSetMode,ScrambleTimeSetMode,orifthescramblefunction
isactivated,"SBC"isilluminated.
IntheWarningBoostSetMode,DropBoostSetMode,orifthewarningfunctionis
activated,"WRN"isilluminated.
２．Display
２．１．DigitalDisplay
１．DigitalDisplay(S)
６．IndicatorDisplay
７．BarGraphDisplay
８．SelectionDisplay
４．UnitDisplay
５．DigitalDisplay（L）
２．Speed/RPMDisplay
３．ThrottleDisplay
