２．３．PoppetValveType
BeforeInstalltion
AfterInstallation
8mmHose
Turbine
Compressor
AirflowMeter
ThrottleValve
AirFilter
Intake
Manifold
FuelPressure
Regulator
6mmHose
6mmHose
4mmHose
4x4x4mm
T‑Fitting
6mmHose
Turbine
Compressor
AirflowMeter
ThrottleValve
AirFilter
Intake
Mainfold
FuelPressure
Regulator
ＥＶＣSteppingMotor
6x8x6mmT‑Fitting
UpperPort
Wastegate
Wastegate
Attachnipple
(Lorstraightnipple)
toupper
port
Toinstallthisunitontoapoppetvalveequippedvehicle,thehosesetforthepoppet
typeisnecessary.
