HKS EVC - Page 18

−17−
BeforeInstallation（BasicConnectionLayout）
AfterInstallation
２．２．３．ForApplicationswithaBoostControlSolenoidValve‑2
6mmHose
Turbine
Actuator
BoostControl
SolenoidValve
Compressor
AirflowMeter
ThrottleValve
AirFilter
Intake
Manifold
FuelPressure
Regulator
6mmHose
4mmHose
4x4x4mm
T‑Fitting
6mmHose
Turbine
Actuator
Boost
Control
Solenoid
Valve
Compressor
AirflowMeter
ThrottleValve
AirFilter
Intake
Manifold
FuelPressure
Regulator
RubberCap
RubberCap
ＥＶＣSteppingMotor
●Bypassthefunctionoftheboostcontrolsolenoidvalvebyremovingtheconnectoror
hose.
VacuumFilter
