−16−
２．２．２．ForApplicationswithaBoostControlSolenoid‑1
BeforeInstallation（BasicConnectionLayout）
AfterInstallation
6mmHose
Turbine
Actuator
BoostControl
SolenoidValve
Compressor
AirflowMeter
ThrottleValve
AirFilter
Intake
Manifold
FuelPressure
Regulator
6mmHose
4mmHose
4x4x4mm
T‑Fitting
6mmHose
Turbine
Actuator
BoostControl
SolenoidValve
Compressor
AirflowMeter
ThrottleValve
AirFilter
Intake
Manifold
FuelPressure
Regulator
RubberCap
RubberCap
ＥＶＣSteppingMotor
●Bypassthefunctionoftheboostcontrolsolenoidvalvebyremovingtheconnectoror
hose.
VacuumFilter
