HKS EVC - Advanced Functions and Inputs

●DualOffsetModeSettings
Ifthedesiredsetboostandtheactualboostlevelsdonotmatch,theoffset
functioncanbeusedtoadjustforthedifference.TheoffsetofbothＡMode&
ＢModecanbesetindividually;therefore,morepreciseresultscanbeobatined.
●WarningFunction
Iftheboostexceedstheuserselectablewarningvalue,theEVCnotifiestheuser
withanaudiablebeepandvisablewarningdisplay.Simultaneously,itlowersthe
boosttothebaselineboostvalueorbyauserpresetvalue.Thisfunctionprevents
damagetotheengineand/ortheturbineduetoover‑boost.
●ThrottlePositionInput
Withthethrottlepositionsensorsignalinput,boostcharacteristicscanbe
tunedinrelationtothrottlepercentage.
●RPMSignalInput
WiththeengineRPMsignalinput,boostcharacteristicscanbetunedin
relationtoRPMlevel.Thisfeatureworksonenginesfrom1to8cylindersand
operatesupto12,000RPM.
●SpeedSignalInput
Withthevehiclespeedsignalinput,boostcharacteristicscanbetunedin
relationtovehiclespeed.Thisfeatureworksonapplicationsthatutilizespeed
pulsesbetween2to16andhasamaximumspeedcapacityof500km/h.
●MapAdjustmentFunction
 InputofthethrottlesignalandtheengineRPMorvehiclespeedsignalscandrawa
3Dmapbyusing2thesesignalsasaxes.Usingthe3Dmapenablestheeasycontrol
oftheboostcharacteristics.(Thesettingrangemustbewithin+/‑120kPa[17.0PSI]
tothebaselineboostsetting.)Thisfunctionisuserselectabletobeonoroff.
●DigitalTripleDataMeter
3digitaldatareadingsofsurgetankpressure,throttlepercentage,andengineRPM
orvehiclespeedcanbedisplayed.
●BarGraphSelection
Thebargraphdisplaycanbesetforboost,throttlepercentage,engineRPMand
vehiclespeed.
●BarGraphPeakHoldFunction
Thepeakholdfunctionofthebargraphdisplaysandholdsthemaximumvalue
achievedforeasyinstantrecognition.
●AfterImageDisplayFunction
Whentheboostchangesfrompositivepressuretonegativepressure,themaximum
positiveboostvalueisdisplayedforafewseconds.Thisfunctionisuser
selectabletobeonoroff.
●DataMemoryFunction
AllsetvaluesaresavedintheinternalmemoryoftheEVC.Therefore,these
settingsarenotlostwhentheignitionisofforifthebatteryisdisconnected.
●ExhaustBypass(wastegatetype)Selection
TheEVCcanworkwithbothinternalandexternalwastegatetypes.
−２−
