HLU HF R 48 R Series User Manual

13
www.hlu.eu
06.2019
Dimensions and design can be changed | Dimensions in mm
Operating manual
Centrifugal fans
HF R | RV | MRV
Type ØD
max.
A
max.
H
max.
RFX
max.
kg
HF R 160-16 160 459 750 850 33
HF R 200-16 200 582 730 1020 41
HF R 250-16 250 710 775 1150 58
HF R 315-16 315 893 965 1350 81
HF R 355-16 355 1008 1090 1450 98
HF R 400-16 400 1126 1250 1450 149
Type ØD
max.
A
max.
H
max.
X
max.
kg.
max.
RFX
max.
kg
HF R 125-15/17 125 366,5 435 504 12
HF R 140-15/17 140 409 462 518 13
HF R 160-15/17 160 464 861,5 725 91 880 99
HF R 180-15/17 180 522 558 629 27 760 28
HF R 200-15/17 200 582 945 812 110 1037 166
HF R 250-15/17 250 732 1040 925 129 1080 174
HF R 280-15/17 280 816 804 768 62 923 56
HF R 315-15/17 315 920,5 1290 1179 260 1334 351
HF R 355-15/17 355 1030 1426 1151 214 1412 352
HF R 400-15/17 400 1141 1562 1255 280 1451 402
HF R 450-15/17 450 1297 1625 1320 310 1546 552
HF R 500-15/17 500 1469 1811 1378 506 1575 691
Type ØD
max.
A
max.
H
max.
X
max.
kg.
max.
RFX
max.
kg
max.
RBX
max.
kg
HF R 450-13 450 1200 1250 1550 1950
HF R 500-13 500 1350 1400 1650 2050
HF R 560-13 560 1575 1860 1471 600 1836 650 2110 750
HF R 630-13 630 1770 2065 1635 950 1965 1000 2155 800
HF R 710-13 710 1985 2310 1710 1150 2040 1200 2405 1200
HF R 800-13 800 2235 2470 1889 1350 2249 1450 2700 1500
HF R 900-13 900 2515 2750 2223 1850 2583 1950 2895 2000
HF R 1000-13 1000 2780 3060 2343 2596 2813 2200 3220 2300
HF R 1120-13 1120 2942 3500 2621 3298 3106 2350 3410 3500
HF R 1250-13 1250 3105 3840 2900 4000 3400 4300 3600 4700
Type ØD
max.
A
max.
H
max.
RFX
max.
kg
HF R 50-48 50 372 605 622 85
HF R 63-48 63 455 640 633 100
HF R 80-48 80 566 705 719 150
HF R 100-48 100 703 805 781 200
HF R 125-48 125 860 950 929 300
HF R 160-48 160 1100 1180 1021 400
HF R 200-48 200 1353 1390 1215 550
