Hobart GPU-600 Series User Manual

OM-2244 / Operation and Maintenance Manual
DCS-600 / Series 500082 / Solid State Transformer-Rectifiers
December 15, 2014
Chapter 1-1
Page 5
1. Front Panel
2. Convenience Receptacle (115 VAC Shown)
3. Starting Current Control
4. Receptacle Fuse
5. DC Voltmeter (M2)
6. Overload/Overvoltage Light (red)
7. DC Ammeter
8. Input Power Light (amber)
9. Output Contactor Light (green)
10. Input Power On-Off Switch
11. Output Contactor Close-On-Off Switch
Figure 4 Front Panel Assembly of GPU-600
1
2
3
4
6
5
8
9
10
11
7

Hobart GPU-600 Series Specifications

General

Brand	Hobart
Model	GPU-600 Series
Category	Transformer
Language	English
